SecuRam Prologic L62 Keypad & Swing Bolt Safe Lock Kit

Simple to Use and Reliable

• OLED Menu system guides the user through access and programming procedures
• View Audit trail records on screen or download wirelessly to Lock Management software or Wireless Link
• Every SECURAM lock undergoes a 2,000 cycle quality management program before it leaves the manufacturing facility
• Unprecedented commitment to quality and reliability

Keypad Features

• 30 Codes: 2 Manager Codes and 28 User Codes
• Super Code for programming management and control
• 1000 event audit trail can be viewed on-screen
• Wireless Audit Download to Wireless Link
• Time Delay 0-99min; Time Window 1-15min
• Time Delay Override Codes – selectable
• Time Delay Override
• OTC Recovery code can be used to reset the controller to factory default
• Single or Dual Control Modes
• Dual Mode Group – set some users in Dual Mode
• Auto DayLight Savings Time
• Ability to choose to Obfuscate Code upon entry
• EntryPad can control up to 4 locks with programmable lock sequence
• Supports single user mode and dual user mode
• Duress mode with programmable shift feature
• SureLock Battery Management and AC power optional
• Standard footprint and mounting pattern, easy retrofit for any mechanical or electronic safe lock
• Finishes available: Chrome
• Can be paired with any other SECURAM motorized safe lock bodies

Swing Bolt Lock Features

• The SwingBolt is our most popular lock body
• The SwingBolt is designed to work in conjunction with most safe boltwork systems
• Upon entry of a valid code the motorized locking mechanism moves to its unlocked position, allowing the safe bolt work to rotate the bolt into the lock case
• The lock remains unlocked for 6 seconds and then automatically relocks
• When the safe door is closed and the safe handle returned to the locked position, the lock will automatically lock secure
• As with all SecuRam lock bodies, the SwingBolt can operate in two modes:
  • Analog mode for use with SafeLogic Series EntryPads
  • Digital mode for use with ProLogic and ScanLogic EntryPads
• See Analog versus Digital Mode video below for instructions to convert the lock from one mode to the other
• The SwingBolt is Bluetooth compatible and can be used in conjunction with SecuRam's Bluetooth EntryPads
• The SwingBolt lock body can be used to replace any standard sized safe lock
• The SwingBolt can be easily retrofitted on most safes
• Available with bolt status sensor

Download ProLogic L62 Data Sheet
